40X100m Curved Marque with AC System for Exhibition and Trade Show
40x100m Curved Marque with AC System for Exhibition and Trade Show 1. Application of Curved Marquee with AC SystemIt is equipped with clear windows, decoration roof lining, inside curtain, pagoda tent entrance.The tent series are widely used as the party tent, wedding tent, exhibition tent, confe......
Send Inquiry
Product Description
40x100m Curved Marque with AC System for Exhibition and Trade Show
1. Application of Curved Marquee with AC System
It is equipped with clear windows, decoration roof lining, inside curtain, pagoda tent entrance.The tent series are widely used as the party tent, wedding tent, exhibition tent, conference tent, festivals celebration tent, corporate events tent or other events, etc.
2. Specification for Curved Marquee with AC System
Liri CBT Series:
· Frame struss: hard pressed extruded aluminium 6061/T6(15HW) which can last more than 20 years.
· Fabric cover: high quality double PVC-coated polyester textile, 100% waterproof, flame retardant to DIN4102 B1, M2, CFM, UV resistant, tear resistant, self-cleaning ability, etc.
· Connector: strong hot-dip galvanized steel
· Allowed temperature condition: -30 degree Celsius~+70 degree Celsius
· Wind load: max. 100km/h (can be reinforced)
· Snow load: 75kg/sqm (snow can't stay if use big degree roof pitch design)
· Easy to be assembled and dismantled, movable.
· No pole inside, 100% available interior space.
3. Optional Accessories of Curved Marquee with AC System
· Covers: colourful cover, transparent cover, inflatable roof cover
· Windows: dome or square clear PVC windows, mesh window, glass window for glass wall
· Wooden Flooring System: VIP cassette flooring, simple cassette flooring
· Doors: double-wing glass door, single-wing glass door, glass fire door, aluminium door, rolling shutter(automatic or manual)
· Wall: soft PVC fabric wall, glass wall, ABS hard wall, sandwich panel wall, steel plate wall
· Fixing Methods: ground anchors, weight plate, expandable bolts
· Rain Gutters:inner roof beam rain gutter or rain gutter between two similar tents
· Other Optional Items: table, chair, lighting, AC, carpet, installation tools etc.
4. Packaing of Curved Marquee with AC System
1. aluminum frame packed in membrane film
2. hardware packed in solid carton box
3. roof and sidewall in professional PVC carry bag
5. Products certificate of Curved Marquee with AC System
· National High-tech Enterprises
· ISO 9001:2008 Quality Control Standards
· IFAI Certificate of Membership
· American Rental Association Associate Membership
· Practical Type Patent Certificate
· Liri Tents Trade Mark Certificate
6. Liri Tent Successful Cases:
· Kinds of New Style Tent for China Open
· Canton Fair Exhibition Hall
· 2011 Universiade Official Tent Supplier
· 2010 Asian Games Exclusive Tent Supplier&Sponsor
· Dior Event in Hong Kong
· China Grand Rally Sponsor
· Hong Kong Wine and Dine Festival
We are a one stop shop for all your tents, event party rental and wedding needs. For more details please Contact us Now!
Contact person: Ivy Lee
Mobile and WhtasApp: + 86 159 1633 2440
1. Application of Curved Marquee with AC System
It is equipped with clear windows, decoration roof lining, inside curtain, pagoda tent entrance.The tent series are widely used as the party tent, wedding tent, exhibition tent, conference tent, festivals celebration tent, corporate events tent or other events, etc.
2. Specification for Curved Marquee with AC System
Liri CBT Series:
| Type | Span Width | Bay Distance | Eave Height | Ridge Height | Main Profile |
| CBT | 15m/49.2' | 5m/16.4' | 3.87m | 8m | 204x120x4mm(4-channel) |
| CBT | 20m/65.6' | 5m/16.4' | 3.87m | 8.8m | 204x120x4mm(4-channel) |
| CBT | 25m/82' | 5m/16.4' | 3.87m | 9.9m | 204x120x4mm(4-channel) |
| CBT | 20m/65.6' | 5m/16.4' | 3.89m | 8.9m | 300x120x5mm(4-channel) |
| CBT | 25m/82' | 5m/16.4' | 3.89m | 10m | 300x120x5mm(4-channel) |
| CBT | 30m/98.4' | 5m/16.4' | 3.89m | 11.2m | 300x120x5mm(4-channel) |
| CBT | 40m/131.2' | 5m/16.4' | 3.89m | 13.5m | 300x120x5mm(4-channel) |
| The length can be extended by 5m bay such as 15m,20m,30m,40m...Customized size or shape is available. | |||||
· Frame struss: hard pressed extruded aluminium 6061/T6(15HW) which can last more than 20 years.
· Fabric cover: high quality double PVC-coated polyester textile, 100% waterproof, flame retardant to DIN4102 B1, M2, CFM, UV resistant, tear resistant, self-cleaning ability, etc.
· Connector: strong hot-dip galvanized steel
· Allowed temperature condition: -30 degree Celsius~+70 degree Celsius
· Wind load: max. 100km/h (can be reinforced)
· Snow load: 75kg/sqm (snow can't stay if use big degree roof pitch design)
· Easy to be assembled and dismantled, movable.
· No pole inside, 100% available interior space.
3. Optional Accessories of Curved Marquee with AC System
· Covers: colourful cover, transparent cover, inflatable roof cover
· Windows: dome or square clear PVC windows, mesh window, glass window for glass wall
· Wooden Flooring System: VIP cassette flooring, simple cassette flooring
· Doors: double-wing glass door, single-wing glass door, glass fire door, aluminium door, rolling shutter(automatic or manual)
· Wall: soft PVC fabric wall, glass wall, ABS hard wall, sandwich panel wall, steel plate wall
· Fixing Methods: ground anchors, weight plate, expandable bolts
· Rain Gutters:inner roof beam rain gutter or rain gutter between two similar tents
· Other Optional Items: table, chair, lighting, AC, carpet, installation tools etc.
4. Packaing of Curved Marquee with AC System
1. aluminum frame packed in membrane film
2. hardware packed in solid carton box
3. roof and sidewall in professional PVC carry bag
5. Products certificate of Curved Marquee with AC System
· National High-tech Enterprises
· ISO 9001:2008 Quality Control Standards
· IFAI Certificate of Membership
· American Rental Association Associate Membership
· Practical Type Patent Certificate
· Liri Tents Trade Mark Certificate
6. Liri Tent Successful Cases:
· Kinds of New Style Tent for China Open
· Canton Fair Exhibition Hall
· 2011 Universiade Official Tent Supplier
· 2010 Asian Games Exclusive Tent Supplier&Sponsor
· Dior Event in Hong Kong
· China Grand Rally Sponsor
· Hong Kong Wine and Dine Festival
We are a one stop shop for all your tents, event party rental and wedding needs. For more details please Contact us Now!
Contact person: Ivy Lee
Mobile and WhtasApp: + 86 159 1633 2440
