Product Description
More information is provided by Superb Tent
Product Description
1. Application:
The high peak Pagoda tents(PA series, Pagoda Tent) can be widely used as the wedding tent, party tent, exhibition tent, conference tent, different kinds of festivals tent, hajj tent, corporate events tent, sports tent, & temporary, semi-permanent or permanent building purpose etc.
2. Materials:
Fabric: Double PVC coated polyester fabric, 650-900g/sq. M, water proof, UV resistance, anti-mildew, self-cleaning, fire retardant according to standard NFPA701 & DIN4102 B1/M2
Frame: Hard pressed extruded aluminum 6061/T6, anodized surface finishing.
Main frame profile size: 65X65X2.5mm;
Connections: Hot-DIP galvanized steel;
3. Life span of fabric(cover & sidewalls): 8-10years;
Life span of aluminum frame: 20-30years
4. Structure safety parameters:
Wind load: 80km/h (0.3kn/M2)
Snow load: 25kg/sq. M
5. Color available: White, red, yellow, blue, green, black, grey, transparent etc
6. Optional Accessories:
Ground anchor, anchor puller, weight plate, glass door, fire door, glass wall, ABS hard wall, Sandwich walls, auto-rolling door, decoration lining, flooring system, clear PVC windows sidewalls, transport rack for the glass door & walls, ramp etc; Chairs, tables, & other furniture for the parties are also provided for your option.
7. Specification for the high peak Pagoda tents(PA series, Pagoda Tent), pls refer to below chart
Product Description
1. Application:
The high peak Pagoda tents(PA series, Pagoda Tent) can be widely used as the wedding tent, party tent, exhibition tent, conference tent, different kinds of festivals tent, hajj tent, corporate events tent, sports tent, & temporary, semi-permanent or permanent building purpose etc.
2. Materials:
Fabric: Double PVC coated polyester fabric, 650-900g/sq. M, water proof, UV resistance, anti-mildew, self-cleaning, fire retardant according to standard NFPA701 & DIN4102 B1/M2
Frame: Hard pressed extruded aluminum 6061/T6, anodized surface finishing.
Main frame profile size: 65X65X2.5mm;
Connections: Hot-DIP galvanized steel;
3. Life span of fabric(cover & sidewalls): 8-10years;
Life span of aluminum frame: 20-30years
4. Structure safety parameters:
Wind load: 80km/h (0.3kn/M2)
Snow load: 25kg/sq. M
5. Color available: White, red, yellow, blue, green, black, grey, transparent etc
6. Optional Accessories:
Ground anchor, anchor puller, weight plate, glass door, fire door, glass wall, ABS hard wall, Sandwich walls, auto-rolling door, decoration lining, flooring system, clear PVC windows sidewalls, transport rack for the glass door & walls, ramp etc; Chairs, tables, & other furniture for the parties are also provided for your option.
7. Specification for the high peak Pagoda tents(PA series, Pagoda Tent), pls refer to below chart
| Type | Span (m) | Side height (m) | Peak height (m) | Bay Distance (m) | Longest Component (m) | Wind Load (km/h) |
| PA3/2.5-3 | 3 | 2.5 | 4.2 | 3 | 3 | 80 |
| PA4/2.5-4 | 4 | 2.5 | 4.8 | 4 | 4 | 80 |
| PA5/2.5-5 | 5 | 2.5 | 5.2 | 5 | 5 | 80 |
| PA6/2.5-6 | 6 | 2.5 | 5.8 | 6 | 6 | 80 |
| PA8/2.6-4 | 8 | 2.6 | 5.4 | 4 | 4 | 80 |
| PA10/2.6-5 | 10 | 2.6 | 6.4 | 5 | 80 | |
| Main frame Profile | 65X65X2.5mm(3-channel,for 3-6m)/122x68x3mm(4-channel,for 8-10m)) | |||||
| Eave Connection | Hot-dip Galvanized Steel Insert | |||||
| Frame Material | Hard Pressed Extruded Aluminum 6061/T6 | |||||
| Cover Material | Double PVC coated Polyester textile, flame retardant to DIN4102 B1,M2,750-900g/sq.m | |||||
